Place of Origin: | Wuxi, China |
Brand Name: | Beli |
Certification: | CE |
Model Number: | YX16.8-200-800 |
Minimum Order Quantity: | 1 |
---|---|
Price: | USD 30000-40000 / set |
Packaging Details: | Nude Packaging |
Delivery Time: | 45 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20 sets/ Month |
Type: | Cold Rolling Machine | Condition: | New |
---|---|---|---|
Warranty: | 18 Months | Voltage: | 380V, 3 Phase, 50Hz |
After-sales Service: | Enigineers Available To Service Machinery Overseas | ||
High Light: | metal roofing roll former,profile roll forming machine |
Description:
This Metal Roof Tile Roll Forming Machine can produce metal roof tiles. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc.
Technical Parameters - YX16.8-200-800 | |
---|---|
Raw Material | Carbon Steel, Galvanized Steel, Q235 |
Material Thickness | 0.3-0.8mm |
Material Width | Depend on specific profile |
Diameter of Shaft | 76mm |
Material of Shaft | 45# steel |
Material of Rolls |
45# steel Chromed with thickness 0.05mm |
Main Power | 7.5KW |
Forming Speed | 3-4m/min |
Forming Station | 18 stations |
Cutting Type | Hydraulic cutting |
Cutting Blade |
Cr12 Mov |
