High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material

High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material

    • High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material
    • High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material
  • High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material

    Product Details:

    Place of Origin: Wuxi, China
    Brand Name: Beli
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Contact Us For Best Price
    Packaging Details: Main machine part is naked packing with high tensile iron wire fixed in the container, electric and hydraulic parts are covered with plastic film.
    Delivery Time: 45 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 sets/ Month
    Contact Now
    Detailed Product Description
    Condition: New Machine Warranty: 2 Years
    After-sales Service: Engineers Available To Serve Machine Overseas

    High Front Quad Gutter Roll Forming Machine For Galvanized Steel, Aluminium, Copper Material



    This gutter roll forming machine is used in manufacturing front high quad gutters with the raw material of galvanized steel, aluminium and copper. Main process of the whole line is decoiling, guiding, roll forming and cutting.



    Main Components Of Quad Gutter Machine

    a. 3Ton Manual Decoiler..................................................... 1 unit
    b. Pinch Roll Feeding.......................................................... 1 unit
    c. Manual Guillotine............................................................. 1 unit
    d. Guiding Device................................................................ 1 unit
    e. Roll Forming Stations...................................................... 1 unit
    f. Hydraulic Cutting Device.................................................. 1 unit
    g. Product Support Tables.................................................. 2 units
    h. Electric Control System................................................... 1 unit
    i. Hydraulic Station.............................................................. 1 unit

    Main Technical Parameters

    1. Applicable Material: Galvanized steel coils, aluminium, copper
    2. Material Thickness: 0.42mm
    3. Main Motor Power: 7.5kw
    4. Forming Stations: 16 stations
    5. Forming Speed: 0-15m/min
    6. Control System: PLC control system
    7. Roller Material: 45# steel with heat treatment and chrome plated with 0.05mm thick
    8. Cutting power: 4kw
    9. Material of Cutting Blade: Cr12Mov





    Packing And Delivery

    a. Main machine part is nude paking with high tensile iron wire fixed it in the container.

    b. Hydraulic and electrical parts are wrapped with plastic film.

    c. Protective mesh cover are wrapped with plastic film.



    Pictures Of Quad Gutter Roll Forming Machine

    High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material   High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material



    High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material   High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material



    High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material   High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material



    High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material   High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material


    High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material   High Front Quad Gutter Making Machine For Galvanized Steel / Aluminium / Copper Material



    If you have any questions or need more machine details, please feel free to contact us.
