High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing

High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing

    • High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing
    • High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing
    • High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing

    Product Details:

    Place of Origin: Wuxi, China
    Brand Name: Beli
    Certification: CE
    Model Number: YX65-225-675

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: USD 38000-45000 / set
    Packaging Details: Nude Packaging
    Delivery Time: 45 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 sets/ Month
    Contact Now
    Detailed Product Description
    After-sales Service: Enigineers Available To Service Machinery Overseas Warranty: 18 Months
    Voltage: 380V, 3 Phase, 50Hz Type: Cold Rolling Machine
    Condition: New
    High Light:

    metal deck forming machine

    ,

    floor deck roll forming machine

    Roll Forming Machine For Closed Floor Decking





    Description:



    This Metal Floor Decking Roll Forming Machine is used to produce metal floor decks which are widely used in steel buildings. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc.  Fully automatically controlled by PLC and operated by touch screen, the machine enjoys high forming speed and makes little noise.


    Technical Parameters - YX65-225-675
    Raw Material Carbon Steel, Galvanized Steel, Q235
    Material Thickness 0.8-1.5mm
    Material Width Depend on specific profile
    Diameter of Shaft 120mm
    Material of Shaft 45# steel
    Material of Rolls

    GCr15 Over quenching HRC 58-62°
    Main Power 11KW*2
    Forming Speed 15-20m/min
    Forming Station 24-32 stations
    Cutting Type Hydraulic cutting
    Cutting Blade

    Cr12 Mov





























    Tag:

    roll forming machine,

    metal deck forming machine,

    floor deck roll forming machine
