Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections

Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections

    • Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections
    • Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections
  • Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections

    Product Details:

    Place of Origin: CHINA
    Brand Name: Believe Industry Company
    Certification: CE
    Model Number: BELI 31-92-150

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Standard Packing
    Delivery Time: 45 days
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Machine: U Channel Roll Forming Machine Material Thickness: 1.5-3mm
    Motor Power: 7.5kw Feeding Width: 112mm; 150mm
    High Light:

    stud roll former

    ,

    stud making machine

    Chain Drive Steel U Channel Roll Forming Machine For 2 Sizes

    Brief Description

    This cold roll forming machine is designed to produce steel U channal sections with galvanized steel coils. 2 sizes of u channel sections can be roll formed through 1 set of rollers by adjusting the spacers between rollers.



    Profile Drawing

    Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections
     Model: 36-63.5-112  Model: 31-92-150
     Feeding Width: 112mm  Feeding Width: 150mm



    Machine Features

    *   1 machine for 2 steel U channel sizes

    *   Integrated machine structure

    *   7-roll leveling device

    *   Chain drive

    *   Turkey straightener

    *   No need change cutting blade for different sizes



    Main Technical Parameters

    1  Main Motor Power  7.5kw
    2  Forming Steps  10 steps
    3  Forming Speed  10-15m/min (not including cutting)
    4  Shaft Material  40Cr
    5  Roller Material  No. 45 steel
    6  Hydraulic Power  5.5kw
    7  Cutting Blade Material  Cr12Mov



    If you need detailed machine parameters, please show us more information

    >   Profile drawing of the product you want to produce

    >   Material, thickness, yield strength you use

    >   If you need punching holes or slots, please show us punching details

    >   For other requirement such as separated machine structure(cassette type roll forming machine, rafted type roll forming machine), high machine speed, automatic decoiler, flying cutting device, autostacker, please show us if needed.



    Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections



    Believe Industry Company with 20+ years' experience in metal roll forming machine industry.

    Contact Us Today To Start Your New Roll Forming Enterprise.



    Chain Driven Steel Roll Forming Equipment For 2 Sizes U Channel Sections
