Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former

Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former

Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former

Product Details:

Place of Origin: Wuxi, China
Brand Name: Beli
Certification: CE
Model Number: YX-35-260-1040

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 30000-40000 / set
Packaging Details: Nude Packaging
Delivery Time: 45 days
Payment Terms: T/T, L/C
Supply Ability: 20 sets/ Month
Contact Now
Detailed Product Description
Type: Cold Rolling Machine Condition: New
Warranty: 18 Months Voltage: 380V, 3 Phase, 50Hz
After-sales Service: Enigineers Available To Service Machinery Overseas
High Light:

roofing sheet roll forming machine

,

profile roll forming machine

New Design Metal Roof Tile Roll Forming Machine | Believe Industry Company

This Metal Roof Tile Roll Forming Machine can produce metal roof tiles as desired drawings. Believe Industry Company have a full range of metal tile machines for different requirements.



What's Roof Tiles?

Roof Tiles are to keep out rain. And traditional made from locally available materials such as slate and terracotta. And modern materials such as concrete, plastic and Metals. Metal Tile is very special and consist of a high percentage of recycled material and is 100% recyclable. And the Metal Roof Tile is also lightweight, can be installed on top of an existing roof. it’s very useful for a large and old structures( such as wooden structure). It is interlocked, so it provides increased wind resistance when compared with other roof materials.



Profile Drawings of Metal Roof Tiles

Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former



Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former



Metal Roof Tile Roll Forming Machine Components

  1. 5 Ton Uncoiler
  2. Feeding and Guiding Device
  3. Roll Forming Machine Mill
  4. Punch and Cutting Device
  5. Collection Table
  6. Controlled Panel
  7. Hydraulic Station

Metal Roof Tile Machine Layout

Metal Roof Tile Roll Forming Machine , Efficient Metal Roofing Roll Former



Uncoiling--Pre-cutting--Roll Forming--Punching--Cutting--Collecting



Main Specifications of Metal Roof Tile Roll Forming Machine

Technical Parameters - YX35-260-1040
Raw Material Carbon Steel, Galvanized Steel, Q235
Material Thickness 0.3-0.8mm
Material Width Depend on specific profile
Diameter of Shaft 76mm
Material of Shaft 45# steel
Material of Rolls

GCr15 Over quenching HRC 58-62°

Main Power 7.5KW
Forming Speed 3-4m/min
Forming Station 18 stations
Cutting Type Hydraulic cutting
Cutting Blade

Cr12 Mov
