Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type

Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type

    • Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type
    • Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type
    • Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type
  • Efficient Downspout Roll Forming Machine Portable Hand Operate Cutting Type

    Product Details:

    Place of Origin: Wuxi, China
    Brand Name: Beli
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: USD 15000-20000 / set
    Packaging Details: Nude Packing (roller surface covered plastic film)
    Delivery Time: 45 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 sets/ Month
    Contact Now
    Detailed Product Description
    After-sales Service: Engineers Available To Service Machinery Overseas Warranty: 18 Months
    Voltage: 380V, 3 Phase, 50Hz Type: Cold Rolling Machine
    Condition: New
    High Light:

    downspout forming machine

    ,

    downpipe roll forming machine

    Portable Downpipe Roll Forming Machine





    Description:



    This portable downpipe roll forming machine is used in manufacturing down pipes and its specific dimension is made at customers' requirements. The main components of this device are decoiler, roll former, cutting device, control cabinet, and pipe bending machine, etc.



    Technical Parameters
    Raw Material Steel, Aluminum, Copper
    Material Thickness 0.3-0.8mm
    Material Width Depend on specific profile
    Diameter of Shaft 50mm
    Material of Shaft 45# steel
    Material of Rolls

    45# steel Chromed with thickness 0.05mm

    Main Power 2.2KW
    Forming Speed 6-8m/min
    Forming Station 11 stations
    Cutting Type Hand Operate
    Cutting Blade

    Cr12 Mov
